ISC2 ISSAP Domain 3.3.2: Architect Infrastructure and System Security

We are living in a world where the lines between our physical and digital lives are blurring faster than a chameleon changing colors. Every day, we see headlines about massive data breaches, ransomware attacks, and crippling cyber-attacks on critical infrastructure. A recent report by Cybersecurity Ventures predicts that cybercrime will cost the world $10.5 trillion annually by 2025. Trillion, with a “T.” That is not just a number; it is a gut punch to every business, every organization, and every individual who relies on technology. So, how do we fight back? The answer is not in a single, shiny tool. It is in the architecture, the foundational blueprint of your entire system. Building a robust infrastructure and system security architecture is no longer optional; it is mission-critical. The year 2024 underscored this urgency with some of the worst data breaches on record, exposing hundreds of millions of records due to weak cloud and network security.

Physical Security Control set (e.g., Cameras, Doors, System Controllers)

Before we discuss firewalls and encryption, we need to consider the real world. That is right, the very ground your servers stand on. You can have the most sophisticated digital defenses, but if a bad actor can just walk into your data center and yank a server, you have already lost. This is where physical security control sets come into play. We are talking about a multi-layered approach:

• Cameras and Surveillance Systems: High-resolution cameras are not just for Hollywood movies. They are your eyes on the ground, monitoring every corner of your data center, server rooms, and even the entry points to your offices. They act as a powerful deterrent and provide a crucial audit trail.
• Doors, Locks, and Access Control: Forget the old-school keys. Modern infrastructure demands biometric scanners, access cards, and keypads. These systems create a digital log of who entered what room and when. The principle of least privilege applies here, too—only give access to the people who absolutely need it.
• System Controllers and Environmental Monitoring: This is the brain of your physical security. These controllers manage everything from HVAC systems to fire suppression. You need to monitor for things like temperature fluctuations, water leaks, and power outages. After all, a fire can be just as destructive as a hacker.

Platform Security (e.g., Physical, Virtual, Container, Firmware, Operating System (OS))

Once the physical hardware is secure, we must protect the platforms: the servers, devices, and operating systems that run our applications.

Firmware and Hardware Security

• Enable UEFI/BIOS passwords, secure boot, and apply firmware updates to thwart low-level malware.
• Use a Trusted Platform Module (TPM) for hardware-based validation to ensure the OS has not been tampered with during boot.

Operating System (OS) Hardening

• Use baseline configurations (like CIS Benchmarks) to disable unnecessary services, enforce strong authentication, and apply patches religiously.
• Follow the principle of least privilege for user accounts and service permissions on every host.
• Many breaches still occur because an OS was left unpatched or misconfigured.

Virtualization Security

• Keep hypervisor software updated and minimize the attack surface (restrict access to management interfaces).
• A vulnerable hypervisor can allow attackers to break out of one virtual machine into others.

Container Security

• Platforms like Docker and Kubernetes offer efficiency but require careful security design.
• Container isolation is not automatic; a misconfigured container or kernel exploit can cause a “container escape”.
• Always configure container security features:
• Use network segmentation for containers.
• Enforce resource limits.
• Keep the container host OS minimal and patched.
• Attackers actively target containers; some upload malware-laden images to public repositories, hoping that someone will download them.
• Counter this by using trusted container images and scanning for vulnerabilities.

Network Security

If physical and platform security form the base of your castle, the network is the series of moats and walls controlling data flow. Modern network security architecture is all about segmentation and controlled access. We still have our trusty firewalls; next-generation firewalls that inspect traffic and enforce policies between network zones (e.g., between the internet and a DMZ, or between user LAN and server VLANs). In an age of both wired and wireless networks, it is critical to secure both. Wired networks need port security and Network Access Control (NAC) (ensuring only authorized devices connect, often via 802.1X authentication). In contrast, wireless networks need strong encryption (WPA3, enterprise authentication) and segmentation for guest vs corporate traffic. Beyond the basics, networks have evolved.

Zero Trust and Software-Defined Perimeter (SDP)

• Adopt Zero Trust: No network traffic is inherently trusted, even within the internal network.
• SDP: Hides infrastructure from outsiders; only visible after authentication and authorization.
• Creates one-to-one secure tunnels between user devices and specific services.

Core Protocols and Services

• DNS: Use DNSSEC and monitor for hijacking/tunneling attempts.
• NTP: Use secure internal NTP; authenticate time sources to protect log integrity.
• VPN/IPsec: Still essential for secure remote access (though ZTNA and SDP are emerging alternatives).

Network Segmentation

• Isolate management networks for admin use only.
• Create out-of-band networks for critical systems.
• Use air-gaps or one-way gateways for highly sensitive environments (e.g., ICS).

Cloud and Software-Defined Networking

• Use cloud security groups and virtual firewalls.
• Replace traditional on-prem firewalls with software-defined perimeters where appropriate.

IoT and VoIP Security

• IoT devices are often attacked within 5 minutes of going online.
• Segment IoT on separate VLANs; restrict access to necessary servers/APIs.
• VoIP: Encrypt traffic (TLS/SRTP) and isolate voice systems in dedicated VLANs with firewall rules.

Storage Security: Protecting Data at Rest

All the fancy network and platform security means little if an attacker can simply steal your data off a disk or backup tape. Storage security focuses on keeping data safe where it lives: on hard drives, SSDs, SAN arrays, backup media, and so on.

A core strategy here is encryption of data at rest. If your storage is encrypted, even if a hard drive is stolen or an old backup tape resurfaces in a dumpster, the data remains unreadable gibberish to anyone without the keys. Yet, many companies fall short in this area; in cloud environments, an eye-opening 91% of database services with sensitive data were found not to be encrypted at rest. Clearly, there’s room for improvement!

Key Storage Technologies

1. Direct-Attached and Networked Storage Security

• Encryption: Use self-encrypting drives or file system/volume encryption (BitLocker, LUKS, cloud encryption).
• Key Management: Store keys in an HSM or cloud KMS; rotate regularly.
• Access Control: Authenticate hosts/users; use zoning or network segmentation to limit storage visibility.

2. Archival and Removable Media Security

• Encryption and Control: Encrypt all backups, tapes, external drives, and USBs before leaving premises.
• Risk Stats: 87% lost/stolen USBs not reported; 80% used unencrypted drives.
• Policies: Mandate encrypted USBs/backups; require immediate reporting of lost devices.
• Extra Measures: Disable USB ports or use endpoint management to control data transfers.

Data Repository Security

If storage security is about drives and disks, data repository security is about the structured locations where data resides, such as databases, data warehouses, file repositories, and big data lakes. These are often the crown jewels attackers seek (think customer databases, intellectual property, personal data). A multi-pronged approach is needed: access control, encryption in the repository, and data masking or redaction where appropriate.

Cloud Security

Migrating to the cloud has been a game-changer for infrastructure, and with it comes a shared responsibility for security. Cloud providers (AWS, Azure, GCP, etc.) handle the security of the cloud (physical data centers, underlying network, hypervisors), but you are responsible for security in the cloud; your workloads, configurations, and data. The stakes are high: as of 2023, 82% of data breaches involved data stored in the cloud, indicating that attackers are increasingly targeting cloud misconfigurations and credentials.

Operational Technology (e.g., Industrial Control System (ICS), Internet of Things (IoT), Supervisory Control and Data Acquisition (SCADA))

Operational Technology (OT) refers to the systems that monitor and control industrial processes; everything from manufacturing plants and power grids to building HVAC systems and even “smart” city infrastructure. These often include Industrial Control Systems (ICS) like SCADA (Supervisory Control and Data Acquisition) systems and PLCs (Programmable Logic Controllers), as well as the newer wave of Internet of Things (IoT) devices that bridge physical and digital (sensors, cameras, smart appliances, etc.). Securing OT is especially critical because a cyber attack here is not just about data; it can disrupt physical operations, cause safety hazards, or economic damage.

A key principle for OT security is the difference between IT and OT. Often implemented as the “Purdue Model” (multi-level network tiers from enterprise IT down to control devices), the idea is to tightly control any connectivity between corporate IT networks and operational networks.

Endpoint Security (e.g., Bring Your Own Device (BYOD), Mobile, Endpoint Detection and Response (EDR), Host-based Intrusion Detection System (HIDS)/Host-based Intrusion Prevention System (HIPS))

Endpoints, whether they are employee laptops, mobile devices, or servers, are where much of the cyber battle is fought. Attackers frequently target endpoints via phishing emails, drive-by downloads, or USB baiting, as compromising an endpoint often provides a foothold into the network. A comprehensive security architecture must address endpoint security with multiple layers. Key components include Endpoint Protection Platforms (EPP) like antivirus/anti-malware, Endpoint Detection and Response (EDR) tools for spotting and isolating suspicious behavior, host-based firewalls, and configuration hardening.

Bring Your Own Device (BYOD) and Mobile

• BYOD introduces unmanaged devices into business networks.
• Mitigate with Mobile Device Management (MDM) or Mobile Application Management: enforce PINs, enable remote wipe, and segregate work data.
• Encrypt disks (such as BitLocker or FileVault) to protect data on lost/stolen devices.
• Keep all devices updated, including the OS, apps, and browsers.

Host-Based Intrusion Detection/Prevention (HIDS/HIPS)

• HIDS monitors system logs and file integrity for anomalies; HIPS can block malicious changes in real-time.
• Complements network IDS/IPS by focusing on on-device threats.

Endpoint Detection & Response (EDR)

• DR tools detect abnormal patterns (e.g., suspicious PowerShell scripts) and act instantly; isolate endpoints or kill malicious processes.
• Integrate EDR alerts into SOC/SIEM for real-time monitoring and faster incident response.

ISSAP Training with InfosecTrain

Designing infrastructure and system security is similar to orchestrating a symphony; many different components (physical, network, cloud, etc.) must work in harmony to create a cohesive defense. We have explored how each layer contributes: physical controls keep intruders out, platform security hardens the computing base, network architecture limits and watches data flows (embracing new paradigms like Zero Trust), storage and data security safeguard the crown jewels (with encryption and good governance), cloud security extends these principles to our new virtual data centers, OT security protects the engines of the real world, and endpoint security secures the devices we use every day.

Now, if you are preparing for the ISSAP exam or looking to build an enterprise-level security architecture that works, InfosecTrain’s ISSAP training has you covered.

From in-depth explorations of network segmentation and Software-Defined Networking (SDN) to real-world case studies on out-of-band management, InfosecTrain’s expert-led sessions bridge the gap between theory and practical implementation. You do not just memorize domains; you master how to apply them in critical infrastructure.

Ready to future-proof your architecture and pass ISSAP with confidence?

Explore InfosecTrain’s ISSAP training and get expert-guided clarity on every layer, every control, and every strategy that matters.
